Connecting Sky Commander to Deep-Sky Planner
The Sky Commander digital setting circles device can be used with Deep-Sky Planner for the Push To operation, and for exporting and sending observing plans to the special object list in the Sky Commander. See Deep-Sky Planner Help for more details about using these features, and for information about communication connection settings.
The connection from your computer to the Sky Commander can be wired (examples 1 and 2 below), or wireless (example 3 below). The wireless example includes a SkyFi unit supplied by Simulation Curriculum. See this article for information about connecting your computer wirelessly to SkyFi.
Notes:
- DB-9 is a serial connector with 9 pins
- RJ-11 is a 6 pin modular connector (ie, telephone jack)
- USB is a standard USB Type-A connector
- The 'DB-9 to RJ-11 cable' mentioned below is supplied by Sky Engineering with Sky Commander.
- The 'RJ-11 to DB-9 cable' mentioned below is supplied by Simulation Curriculum with SkyFi.
- The 'USB to DB-9 adapter' mentioned below is available from Keyspan and others.
